V2

V2

The 3-way quad amplified design, the transducers resources are among the characteristics giving V2 an exceptional ability to perform in many applications and with a record-breaking performance/weight ratio. A V2 line source Inter-element angles can be set with laser like accuracy up to a generous 10˚, allowing the optimization of the vertical coverage with SPL smoothly spread across the audience. Horizontally, the V2 coverage pattern can be adjusted to sector and match any audience or specific room geometries. Thanks to its full range capability, the V2 enclosure can be deployed as a standalone line source. For applications demanding extreme LF impact or maximized LF projection.
The V2 system flexibility makes it suited to both permanent installation applications, from theatre or live house to stadium productions.


Specifications

Model V2
Frequency response 33Hz~20kHz (Processed)
Maximum SPL* 146dB* (Processed)
Power handling capacity(Program) LF:2x1000W/MF:1600W/HF:440W
Nominal impedance LF:2×8Ω/MF:8Ω/HF:16Ω
Horizontal 110°
Vertical dependent upon the number of elements and the line source curvature
HF driver 2×3″, diaphragm compression driver neodymium
MF driver 4×6.5″, weather-resistant , bass-reflex
LF driver 2×12″, weather-resistant , bass-reflex
Application Minimum 2,maximum 16 units line array
Connects IN/LINK: 2x 8-point PA-COM /LINK: 1×8-point PA-COM® parallel
Cabinet 15mm birch plywood made by CNC
N.W/G.W 73kg / 80kg
Product Dimensions W1300xH338xD500mm
Package Dimensions W1386xH688xD562mm
The above packing dimensions, net weight, and gross weight are for reference only. The accurate values are subject to the identification on the batch of products.

Remark:
* Peak level at 1m under half space conditions using pink noise with crest factor 4.
Verity Audio reserves the right to make any changes to the product specifications without prior notice. Final specifications to be found in the user manual.

Dimensions

V2
